9-14
Chapter 9 LUBR
ICATION SYSTEM
2.2
Oil Pump and Safety V
alv
e - Disassemble
and Inspect
Oil Pump and Safety V
alve - Disassemble and Inspect
1
2
3
4
6
10
7
9
5
8
Contact, peeling, wear
Contact, peeling, wear
Flaw, wear
Flaw, crack
Flaw, wear
Replace
Settling, breakage, wear
Flaw, crack
Disassembling Sequence
1
Safety valve assembly
2
Oil pump cover
3
Bushing
4
Driven gear
5
Washer, nut
6
Oil pump gear
7
Drive gear
8
Bushing
9
Oil pump case
10
Shim
