Mitsubishi S12A2 - Left Side View - S12 A2-PTK; Right Side View

To Next Page

To Previous Page

1-10

Chapter 1 GENERAL

Left Side View

Right Side View

S12A2-PTK

Note: Configuration may differ depending

on the customization and specifications.

Oil filler

Fuel filter(wire mesh type)

Air cooler

Fuel return port

Starter

Fuel inlet

Fuel injection pump

Water drain cock

Fuel feed pump

Oil level gauge

Stop solenoid

Fuel filter

Engine cooling

water inlet

Engine cooling

water outlet

Turbocharger

Stop lever

Breather

Actuator

Rear

Front

S12A2-PTK

Note: Configuration may differ depending

on the customization and specifications.

Oil filter

Fuel injection pump

Fuel feed pump

Oil cooler

Fuel filter

Water drain cock

Bypass oil filter

Starter

Front

Rear

Air cooler
