12-9
Chapter 12 AIR START SYSTEM
2.4
Distributer V
alve - Disassemble and Inspect
Distributer V
alve - Disassemble and Inspect
1
3
2
7
8
9
6
5
42
Crack, wear
Crack, wear
Replace
Replace
Replace
Settling
Air direct starting spec
Disassembling Sequence
1
Case cover
2
Packing
3
Distributer valve, lock pin
4
Snap ring
5
Distributer shaft
6
Bushing
7
Distributer case
8
Distributer spacer
9
Packing
316
318
