9-11
Chapter 9 LUBRICATION SYSTEM
1.7
Oil
Pan, Oil S
trainer and O
il Pump - Remove and Inspect
Oil Pan, Oil S
trainer and Oil Pump - Remove and Inspect
Deep
Deep
Replace: Gasket, O-ring
1
1
2
2
3
5
6
4
Land
Removing Sequence
1
Oil pan
(Standard type: approx. 48 kg [105 lb])
(Deep type: approx. 80 kg [176 lb
]
2
Packing
3
Strainer support
4
Oil pump assembly
5
Oil strainer
6
Oil pipe
