9-3
Chapter 9 LUBRICATION SYSTEM
Chapter 9 LUBRICATION SYSTEM
1.
Lubrication System -
Remove and Inspect
1.1
Oil
Pipe - Remove
Oil Pipe - Remove
Replace: Gasket
O-ring
Crankcase
Crankcase
Distributor
Drive case
2
11
11
1
8
7
6
7
3
4
5
9
9
10
D
r
i
ve
ca
se
R
ight
s
ide
injec
t
ion pum
p
4
3
Electronic
governor spec
Electronic governor spec
Removing Sequence
1
Right drain pipe
2
Right oil pipe
3
Right oil pipe
4
Left oil pipe
5
Left oil
pipe
6
Left drain pipe
7
Oil pipe
8
Oil pipe
9
O
il drain pip
e
10
Oil pipe
11
Oil dr
ain pip
e
220
222
