10-4

Chapter 10 COOLING SYSTEM

1.2 Tension Pulley - Remove and Inspect (Fan side)

Tension Pulley - Remove and Inspect (Fan side)

Crack, wear

PTA2 spec

Removing Sequence

1 Tension bolt

2 Mounting bolt

3 Belt

4 Tension pulley assembly
