Mitsubishi S12A2 - Timing Gear Backlash - Measure; Idler Gear End Play - Measure; Camshaft End Play - Measure

5-10
Chapter 5 DISASSEMBLY OF BASIC ENGINE
2.4 Timing Gear Backlash - Measure
Measure the timing gear backlash, and know the current
condition.
For the measurement procedure, refer to "Timing Gear
Backlash - Measure" of "ASSEMBLY OF BASIC
ENGINE."
Timing Gear Backlash - Measure
2.5 Idler Gear End Play - Measure
Measure the idler gear end play, and know the current con-
dition.
For the measurement procedure, refer to "Idler Gear End
Play - Measure" of "ASSEMBLY OF BASIC ENGINE."
Idler Gear End Play - Measure
2.6 Camshaft End Play - Measure
Measure the camshaft end play, and know the current condi-
tion.
For the measurement procedure, refer to "Camshaft End
Play - Measure" of "ASSEMBLY OF BASIC ENGINE."
Camshaft End Play - Measure
Camshaft gear
Camshaft gear
Fuel injection
Fuel injection
pump gear
pump gear
Idler gear
Camshaft gear
Fuel injection
pump gear
Idler gear
Camshaft gear
