Mitsubishi S12A2 - Changeover Spec

8-16
Chapter 8 FUEL SYSTEM
Fuel Filter (Paper Element) - Disassemble, Inspect and Assemble
1
5
4
2
3
Crack, flaw
Use the filter wrench to remove
the fuel filter cartridge.
(Use only when removing)
Filter wrench
Replace
Dent
Changeover spec
Air vent plug
9 ± 1 N·m
{0.9 ± 0.1 kgf·m}
[6.6 ±0.7 lbf·ft]
Replace
Disassembling Sequence
1 Fuel filter cartridge
2 Pin
3 Cover
4 Cock
5 Fuel filter bracket
