12-8
Chapter 12 AIR START SYSTEM
2.3
S
tarter V
alve - Assemble
S
tarter V
alve - Assemble
Air direct starting spec
Lapping:
Using lapping compound,
make sure that valve seat face
shows a uniform contact all
around the circumference.
Application of engine oil
to valve sliding portion.
Be sure to attach gasket.
V
alve lift
3.5
±
0.3
mm
[0.138 ±
0.012 in.]
147 ± 7.35 N·m
{15 ± 0.75 kgf·m}
[108.4
± 5.42
lbf·ft]
19 ± 0.95 N·m
{1.94 ± 0.09 kgf·m}
[14
± 0.7
lbf·ft]
315
317
