10-38
Chapter 10 COOLING SYSTEM
2.13
Sea W
a
ter Pump -
Disassemb
le and Insp
ect
Sea W
ater Pump - Disassemble and Inspect
1
2
4
6
5
13
12
7
8
9
10
14
15
11
12
3
Lip face wear
, deterioration
Wear
, deterioration
Settling, crack, flaw
Rotation
Rotation
Replace
Replace
Spline wear
Wear
, flaw
MTK,MPTK spec
Disassembling Sequence
1
Cover
2
Impeller, impeller cover
3
Case
4
Plate
5
Snap ring
6
Bushing, unit seal
7
Slinger
8
Nut, washer
9
Pulley
10
Snap ring
11
Shaft, key
12
Bearing
13
Oil seal
14
Holder
15
Cam
279
