Mitsubishi S12A2 User Manual

12-11
Chapter 12 AIR START SYSTEM
2.6 Distributer Valve - Assemble
Distributer Valve - Assemble
Note: Align the match marks to assemble the distributer. The wrong assembling results in 360° timing error of air blow and the
engine will not start.
3. Air Start System - Install
Install the parts in the reverse order of the disassemble sequence. (Refer to the illustration for disassembling.)
3°
9°
14°
(
65°
)
9°
9°
3°
3°
No.3 cylinder top
(No.4)
No.5 cylinder top
(No.2)
No.1 cylinder top
(No.6)
No.1 exhaust valve open
6°
120°
120° 120°
A
i
r
i
n
f
l
o
w
1
2
6
°
Overlap
Starting air blowing timing diagram
Air direct starting spec
Fitting
Application of oil
Match mark
Rotation
direction
