11-10

Chapter 11 INLET AND EXHAUST SYSTEMS

1.4 Exhaust Manifold - Remove and Inspect

Exhaust Manifold - Remove and Inspect

Crack, flaw, deformation

Replace: Gasket

Removing Sequence

1 Coupling

2 Flexible joint

3 Exhaust manifold
