Chapter 11 INLET AND EXHAUST SYSTEMS

Air cooler - Disassemble, Inspect and Assemble

Replace

MTK,MPTK spec

Replace

Disassembling Sequence

1 Air duct 2 Air cooler assembly

(One piece approx. 74 kg [163 lb])

3 Center duct
