Mitsubishi S12A2 - Air Duct and Air Cooler - Remove and Inspect (MTK,MPTK Spec)

11-5
Chapter 11 INLET AND EXHAUST SYSTEMS
Air Duct and Air cooler - Remove and Inspect
Replace
Crack, flaw, deformation
Crack, flaw,
deformation
Crack, flaw,
deformation
Crack, flaw, deformation
Crack, flaw,
deformation
Crack, flaw,
deformation
7
6
7
1
8
8
3
9
3
4
5
2
1
2
5
6
4
MTK,MPTK spec
Turbocharger
Turbocharger
Replace
Replace
Replace
Replace
Replace
Replace
Replace
Replace
Removing Sequence
1 Coupling
2 Duct
3 Duct
4 Oil pipe
5 Inlet manifold (Approx 36.4 kg [80 lb])
6 Spacer
7 Air duct
8 Air duct
9 Air cooler (approx. 180 kg [397 lb.])
