9-13
Chapter 9 LUBRICATION SYSTEM
2.
Lubrication System - Disa
ssemble, Inspect and Assemble
2.1
Oil
strainer - Disassemble and Inspect
Oil strainer - Disassemble and Inspect
2
1
Replace
Replace
Replace
Replace
Clogged strainer hole:
W
ash with diesel fuel
Disassembling Sequence
1
Oil strainer
2
Oil pipe
230
232
