Mitsubishi S12A2 User Manual

INSPECTION RECORD SHEET
No. 8(2/2)
Item Piston pin bore diameter
Piston pin outside diameter
Clearance
--
8
No.
Directio
n
XYXYMaximum
--
A
B
9
10
11
12
Approved by Checked by Measured by
Remark
--
B
C- -
--C- -
A
A
B
--
B
C- -
--C- -
A
A
B
--C- -
B
7
C
A
Measured value
57.970
[2.2823]
Piston pin
outside diameter
䃥58
[2.28]
57.987 to 58.000
[2.2829 to 2.2835]
Minimum
Standard Limit
58.040
[2.2850]
Piston pin bore
inside diameter
䃥58
[2.28]
58.002 to 58.012
[2.2835 to 2.2839]
Measuring location Standard
Item to be measured
Nominal
Item
Piston pin bore inside diameter and piston pin outside
diameter - measure(2/2)
Unit mm[in.]
S
A
Customer
Engine Model
Date
Serial No.
