2-11
Chapter 2 SERVICE DATA
Governor drive
S3S spec
(Drive case
P/N:
32625-15100)
Inside diameter of case bearing
housing
ø47 [1.85]
46.989 to 47.014
[1.8500 to 1.8509]
ø80 [3.15]
79.988 to 80.018
[3.1491 to 3.1503]
ø90 [3.54]
89.987 to 90.022
[3.5428 to 3.5442]
Inside diameter of case cover bear-
ing housing
ø47 [1.85]
46.989 to 47.014
[1.8500 to 1.8509]
ø62 [2.44]
61.988 to 62.018
[2.4405 to 2.4416]
ø72 [2.83]
71.988 to 72.018
[2.8342 to 2.8353]
Drive case
bearing
Out-
side
diame-
ter
Small ø47 [1.85]
46.890 to 47.000
[1.8461 to 1.8504]
Middle ø80 [3.15]
79.987 to 80.000
[3.1491 to 3.1496]
Large ø90 [3.54]
89.985 to 90.000
[3.5427 to 3.5433]
Inside
diame-
ter
Small ø20 [0.79]
19.990 to 20.000
[0.7870 to 0.7874]
Middle ø40 [1.57]
39.988 to 40.000
[1.5743 to 1.5748]
Large ø40 [1.57]
39.988 to 40.000
[1.5743 to 1.5748]
Drive case
cover
bearing
Out-
side
diame-
ter
Small ø47 [1.85]
46.890 to 47.000
[1.8461 to 1.8504]
Middle ø62 [2.44]
61.987 to 62.000
[2.4404 to 2.4409]
Large ø72 [2.83]
71.987 to 72.000
[2.8341 to 2.8346]
Inside
diame-
ter
Small ø20 [0.79]
19.990 to 20.000
[0.7870 to 0.7874]
Middle ø30 [1.18]
29.990 to 30.000
[1.1807 to 1.1811]
Large ø35 [1.38]
34.988 to 35.000
[1.3775 to 1.3780]
Outside diameter of drive shaft
bearing fit
ø35 [1.38]
35.002 to 35.013
[1.3780 to 1.3785]
ø40 [1.57]
40.002 to 40.013
[1.5749 to 1.5753]
Unit: mm [in.]
Item Nominal value Standard value
Limit
value
Remarks
