Motorola MC9190-G Integrator Guide

A - 8 MC9190-G Integrator Guide
Table A-4 SE 1524 Decode Distances
Symbol Density/
p/n / Bar Code Type/
W-N Ratio
Bar Code Content/
Contrast
Note 1
Typical Working Ranges
Near Far
7.5 mil
64-17452-01
Code 39; 2.5:1
ABCDEF
80% MRD
2.0 in
5.08 cm
22.0 in
55.88 cm
10 mil
64-17454-01
Code 39; 2.5:1
ABCDE
80% MRD
4.0 in
10.16 cm
34.0 in
86.36 cm
15 mil
64-17417-01
Code 39; 2.5:1
ABCD
80% MRD
5.0 in
12.70 cm
71.0 in
180.34cm
20 mil
64-17456-01
Code 39; 2.2:1
123
80% MRD
5.0 in
12.70 cm
96.0 in
243.84 cm
55 mil
64-17458-01
Code 39; 2.2:1
CD
80% MRD
15.0 in
38.10 cm
180.0 in
457.20 cm
70 mil reflective
64-08780-01
Code 39; 3:1
123477
Reflective
80% MRD
Note 4 367.0 in
932.18 cm
100 mil reflective
64-16990-01
Code 39; 3:1
123456
Reflective
80% MRD
Note 4 542.0 in
1376.68 cm
Notes:
1. CONTRAST measured as Mean Reflective Difference (MRD) at 670 nm.
2. Near ranges are largely dependent upon the width of the bar code.
3. Working range specifications at temperature 23 °C.
4. Near range on reflective bar codes determined by degree of reflectivity and width of bar code.
