Application Deployment for Windows CE 5 - 13
Figure 5-10
Select Source File Window
12. Select the hex files and the click Open.
13. Click the SEND DATA button. The hex file is downloaded to the MC9190-G.
Figure 5-11
Download Complete Screen
14. On completion, press ENTER to return to the Bootloader main screen to select the next file to download.
15. To exit Bootloader, select Exit from the Bootloader main screen and press ENTER.
Bootloader Error Detection
While receiving data, Bootloader performs many checks on the data to ensure that the data is received correctly. If
an error is detected, Bootloader immediately aborts the download, and reports the error on an error screen.
This error message screen displays until a key is pressed. Once the screen is acknowledged, Bootloader returns to
the main menu to wait for a new selection.
Splash screen
##########) 100%
Download complete
in - 0.042 seconds
(1854142 bytes/second)
Hit Enter to Acknowledge
