B - 6 MC9190-G Integrator Guide
1. Tap Select to open the Select Auto-Launch Application window.
2. Select a File Type in the drop-down list.
3. Select a folder (as needed).
4. Select a file name in the list.
5. In the Program arguments field, enter command line parameters.
6. Tap OK.
The selected application appears in the text box.
•
Redirect wireless LAN - When checked, iDockIt ensures that any existing wireless connection is redirected
so that it does not conflict with iDockIt settings.
If iDockIt is configured for a Work connection and the wireless LAN is also configured for Work, iDockIt
switches the wireless LAN to The Internet and vice versa.
•
Detect serial to ethernet cradle - This option is not used.
•
Serial cradle baud rate - Specifies the baud rate iDockIt should use for a serial connection to the Ethernet
cradle. Set this rate to match the baud rate configured for the cradle. For maximum performance, always use
the maximum baud rate of 115200.
If using a USB-to-Ethernet cradle, the USB driver automatically determines the connection speed.
Direct Tab
If using a serial or USB cradle or connect to the MC9190-G with a serial or USB cable, automatically synchronize
with the connected host computer. Alternatively, if the host computer supports RAS connections, connect to a
network through a host computer and/or launch a specified application on the MC9190-G.
Figure B-3
Direct (Serial/USB) Settings Tab
•
Launch ActiveSync - Launches ActiveSync when the MC9190-G is placed in a serial or USB cradle or when
connected to a serial or USB cable. If the MC9190-G has a partnership with the host computer, ActiveSync
automatically synchronizes with the host computer.
NOTE Selecting this option automatically deselects Establish network connection to and Launch application.
Similarly, selecting Establish network connection to or Launch application automatically deselects
Launch ActiveSync.
