Using iDockIt B - 17
Delete An Existing Modem Connection
1. In the Connect using list, select the modem connection you want to delete.
2. Tap Delete.
3. The Modem Settings dialog asks you to confirm that you want to delete the named modem connection. Tap
Yes.
The modem connection is removed from the drop-down list.
Status Tab
The Status tab displays connection-related events as they occur. Check Display status when cradled on the
General tab to display this tab automatically whenever the MC9190-G is placed in a cradle.
Figure B-10
Status Tab
•
Dock Status - Indicates Docked and the type of connection (Serial, Ethernet or USB) when the MC9190-G
is cradled or Not docked when the MC9190-G is removed from the cradle.
•
Connection - Displays the name of the connection.
•
IP Addresses - Displays all valid IP addresses assigned to the MC9190-G. When the MC9190-G is not
cradled, displays either the IP address of the network adapter or, if no network connection, a default IP
address.
•
Status window - Displays a scrolling list of cradle events as they occur, including:
• AC power ON and AC power OFF when the MC9190-G is inserted and removed.
• Carrier detect, baud rate, and (cradle type) connect when iDockIt identifies the cradle and connection
speed.
• Launch (application) when iDockIt launches the selected application, followed by confirmation when the
application has been launched successfully.
• Sync done when synchronization has completed successfully.
• Dismiss (error message) when iDockIt dismisses a message you have designated.
• Dock event complete when iDockIt has completed all defined tasks. If the MC9190-G is removed from
the cradle before this item appears, regardless of dock status, you may interrupt assigned tasks.
Tap Clear to empty all events from the Status window.
