Technical Specifications A - 17
Table A-8
SE4600 Decode Distances
Symbology
Bar Code Content/
Contrast
Typical Working Range
@ 25 Ft-cd Minimum
Near Far
5 mil Code 39 ABCDEFGH
MRD=80%
10 in.
25.4 cm
26 in.
66.0 cm
7.5 mil Code 39 ABCDEF
MRD=80%
8.5 in.
21.6 cm
38 in.
96.5 cm
10 mil Code 39
(Note 2)
ABCDE
MRD=80%
6.5 in.
165.1 cm
44 in.
111.8 cm
15 mil Code 128 1234
MRD=80%
7 in.
17.8 cm
49 in.
124.5
20 mil Code 39 123
MRD=80%
8 in.
20.3 cm
100 in.
254.0 cm
40 mil Code 39 AB
MRD=80%
22 in.(Note 8)
55.9 cm
170 in.
431.8 cm
55 mil Code 39 CD
MRD=80%
26 in.(Note 8)
66.0 cm
230 in.
584.2 cm
100 mil Code 39 12
3:1
MRD=80%
30 in.(Note 8)
76.2 cm
360 in.
914.4 cm
70 mil Reflective Code 39
(Note 4)
123469 46 in.(Note 8)
116.8 cm
288 in.
731.5 cm
100 mil Reflective Code 39
(Note 4)
1234 50 in.(Note 8)
127 cm
360 in.
914.4 cm
Notes:
1. At 23
o
C.
2. 6.5 inches achievable with near LED (on the right when facing the front of the engine) on and far LED off.
3. Test bar codes with 2 internal LEDs flashing with 1.2A peak current, at ambient light of minimum 25 foot-candle
in the plane of the bar code.
4. Mount reflective bar codes on white or black background with minimum 4" border. Luminance in the line-of-sight
direction should be 50-120 cd/mm
2
. Ensure there is no extraneous illumination or shadow on the bar code and that
it is centered within the aiming pattern.
5. Reading criteria: 3 successful decodes out of 4 consecutive frames after setting autoexposure.
6. Provide a baffle if needed to prevent stray light from getting into the sensor fields of view.
7. Distances are measured from the front face of the scan engine chassis.
8. Near range may be closer with shorter bar codes.
9. Dependent on length of bar codes.
