Technical
Specifications
A
-
19
8
GND
Ground, 2.5A max.
9
RI
RS232C
10
CRADLE_DET
Grounded by cradle when in cradle
11
DTR
RS232C
12
Not connected
Not connected
13
POWER_IN
12V, 2.5A max
14
CTS
RS232C
15
USB_5V_DET
USB
16
USB_D_MINUS
USB
17
EXT_PWR_OUT
3.3V @500mA
Table
A-9
Pin-Outs (Continued)
PIN
Number
Signal
Name
Function
146
148
Table of Contents
Default Chapter
5
Revision History
5
Table of Contents
7
About this Guide
15
Introduction
15
Documentation Set
15
Configurations
15
Software Versions
16
AKU Version for Mobile 6.5 Devices
16
OEM Version
16
Btexplorer Software
16
Fusion Software
16
Chapter Descriptions
17
Notational Conventions
17
Related Documents and Software
18
Service Information
18
Chapter 1 Getting Started
19
Introduction
19
Unpacking the MC9190-G
19
Configuring the MC9190-G
19
Resetting the MC9190-G
20
Windows CE 6.0 Devices
20
Performing a Warm Boot
20
Performing a Cold Boot
20
Windows Mobile 6.5 Devices
20
Performing a Warm Boot
21
Performing a Cold Boot
21
Performing a Clean Boot
21
Battery Management
22
Battery Saving Tips
22
Changing the Power Settings
22
Changing the Display Backlight Settings
22
Changing the Keypad Backlight Settings
23
Turning off the Radios
23
On Devices with Mobile 6.5
23
WLAN Radio
24
Bluetooth Radio
24
On Device with CE 6.0
24
Chapter 2 Accessories
25
Introduction
25
Keypads
28
Replacing the Keypad
28
Secure Device (SD) Card
29
Single Slot Serial/Usb Cradle
31
Setup
32
Battery Charging Indicators
33
Four Slot Ethernet Cradle
34
Setup
35
Battery Charging Indicators
35
Ethernet Communication Setup
36
Installing Mobiledox Cradle Manager
36
Installing Idockit
36
MC9190-G Configuration
37
DHCP Server Configuration
37
Cradle Configuration
37
Four Slot Charge Only Cradle
41
Setup
42
Battery Charging Indicators
42
Four Slot Spare Battery Charger
43
Setup
44
Spare Battery Charging with the Four Slot Spare Battery Charger
44
Battery Charging Indicators
44
Magnetic Stripe Reader
45
Attaching and Removing
46
Setup
46
Battery Charging Indicators
47
Serial/Usb Connection
47
Using the MSR
47
Cable Adapter Module
48
Attaching and Removing
49
Setup
49
Battery Charging Indicators
50
Serial/Usb Connection
50
Universal Battery Charger (UBC) Adapter
51
Inserting and Removing a Battery
51
Setup
52
Battery Charging Indicators
52
Modem Module
53
Setup
54
Connecting to the MC9190-G
54
Connecting to the Single Slot Serial/Usb Cradle
55
Configuring the MC9190-G for the Modem (Windows Mobile 6.5)
55
Configuring the MC9190-G for the Modem (Windows CE 6.0)
56
Connecting the Modem (Windows Mobile 6.5)
56
Connecting the Modem (Windows CE 6.0)
56
Changing the Initialization String (Windows CE 6.0)
56
Serial Communication Setup
58
Setting up a Connection on the MC9190-G (Windows Mobile 6.5)
58
Serial Connection Setup (Windows CE 6.0)
59
USB Host Communication Setup
61
Wall Mounting Bracket and Shelf Slide
62
Installing the Wall Mount Bracket
62
Attaching the Shelf Slide to the Wall Mount Bracket
63
One Single Slot Cradle/Four Slot Battery Charger
63
Two Single Slot Cradles/Four Slot Battery Chargers
63
Four Slot Cradle
64
Installing the Cradle/Charger on the Bracket
64
Chapter 3 Synchronization
67
Introduction
67
Installing the Sync Software
67
MC9190-G Setup
68
Setting up a Sync Connection
68
Activesync
68
Windows Mobile Device Center
69
Setting up a Partnership with a Windows CE 6.0 Device
70
Synchronization with a Windows Mobile 6.5 Device
72
Chapter 4 Wireless Applications
75
Introduction
75
Windows CE Devices
75
Windows Mobile 6.5 Devices
76
Fusion Applications
77
Signal Strength Icon
77
Turning off the Radio
78
On Device with Windows CE
78
On Device with Windows Mobile
78
Chapter 5 Application Deployment for Windows CE
81
Introduction
81
Packaging
81
Software Installation on Development PC
81
Platform SDK
82
EMDK for C
82
Installing Other Development Software
83
Software Updates
83
Windows CE Flash Storage
83
FFS Partitions
83
Working with FFS Partitions
83
Regmerge.dll
84
Copyfiles
84
Non-FFS Partitions
84
Downloading Partitions to the MC9190-G
85
Bootloader
85
Partition Update Vs. File Update
85
Upgrade Requirements
85
Deployment
86
Copying Files from a Host Computer
86
Adding Programs
87
Adding a Program from the Internet
88
Updating Images
88
Windows CE 6.0 Osupdate Loader
88
Bootloader
89
Bootloader Error Detection
93
Mobility Services Platform
95
Creating a Splash Screen
96
Chapter 6 Application Deployment for Windows Mobiles
97
Introduction
97
Security
97
Application Security
97
Digital Signatures
97
Locking down a MC9190-G
98
Installing Certificates
99
Device Management Security
99
Remote API Security
99
XML Provisioning
100
Creating an XML Provisioning File
100
XML Provisioning Vs. Regmerge and Copy File
100
Regmerge
101
Copyfiles
101
Packaging
102
Software Installation on Development PC
102
EMDK for C
103
Installing Other Development Software
103
Software Updates
103
Windows Mobile File Storage
103
Random Access Memory
103
Volatile File Storage (Cache Disk)
104
Persistent Storage
104
Application Folder
104
Deployment
104
Installation Using Activesync
105
Installation Using Storage Card
105
Installation Using USB Connection
105
Installation Using Airbeam
106
Mobility Services Platform
106
Update Loader Image
106
Download Update Loader Package
106
Activesync
107
SD Card
107
Creating a Splash Screen
107
Chapter 7 Interactive Sensor Technology Configuration
109
Introduction
109
IST Menu
109
General Tab
110
Power Management Tab
111
Keep Alive on Motion
111
On Face down
111
Wake up on Motion
112
Setting Sensitivity
112
Display Tab
112
Event Log Tab
113
Motion Event Details
113
Chapter 8 Maintenance & Troubleshooting
115
Introduction
115
Maintaining the MC9190-G
115
Battery Safety Guidelines
115
Cleaning
116
Approved Cleanser Active Ingredients
116
Harmful Ingredients
117
Cleaning Instructions
117
Special Cleaning Notes
117
Materials Required
117
Cleaning the MC9190-G
117
Housing
117
Display
117
Scanner Exit Window
117
Battery Contacts
117
Cleaning Cradle Connectors
118
Cleaning Frequency
118
Troubleshooting
119
Mc9190-G
119
Bluetooth Connection
121
Four Slot Charge Only Cradle
122
Four Slot Ethernet Cradle
122
Four Slot Spare Battery Charger
124
Single Slot Serial/Usb Cradle
124
Cable Adapter Module
125
Magnetic Stripe Reader
126
Modem Module
127
Appendix A Technical Specifications
129
MC9190-G Specifications
129
Decode Zones
133
SE960 Standard Range Laser Decode Zones
133
SE1524 Long Range Laser Decode Zones
135
SE4500 Standard Range Imager Decode Zones
137
Se4500-Sr
137
Se4500-Dl
139
Se4500-Hd
141
SE4600 Long Range Imager Decode Zones
143
Mobile Computer Pin-Outs
146
Accessory Specifications
148
Single Slot Serial/Usb Cradle
148
Four Slot Ethernet Cradle
148
Four Slot Charge Only Cradle
149
Four Slot Battery Charger
149
Magnetic Stripe Reader
150
Accessory CAM and MSR Pin-Outs
150
Appendix B Using Idockit
153
Introduction
153
General Recommendations
154
Prepare the MC9190-G to Connect
154
Enable Idockit to Manage Connections Automatically
154
Enable Idockit to Manage Connections Manually
154
Launch Application Upon Connection
155
View Connection Status
155
Minimize Idockit
155
Exit Idockit
155
Windows Mobile 6.5 Configuration
156
General Tab
156
Ethernet Tab
157
Direct Tab
158
Modem Tab
159
Create a New Modem Connection
160
Edit an Existing Modem Connection
161
Delete an Existing Modem Connection
161
Status Tab
161
Windows CE 6.0 Configuration
163
General Tab
163
Ethernet Tab
164
Direct Tab
165
USB Notes
166
Modem Tab
167
Create a New Modem Connection
168
Edit an Existing Modem Connection
168
Delete an Existing Modem Connection
169
Status Tab
169
Un-Installing Idockit
170
Appendix C Special Software Configurations
171
Bluetooth Configuration Setting
171
Sample Applications and Startupctl Configuration
172
Startupctl Application Configuration
172
Removing Sample Applications and Startupctl Application
172
Switching between QVGA and VGA Resolution in Windows CE Devices
173
Battery Usage Threshold Setting
174
Registry Setting
174
WLAN Default Settings
175
