Technical Specifications A - 23
Table A-15
CAM and MSR Serial Connector Pin-outs
Pin Signal
1 USB_5V_DET
2 USB_D_MINUS
3 USB_D_PLUS
4 GND
5 GND
6 PWR_EXT_OUT
7 CRADLE_DET*
8 DSR
9 DCD
10 TXD
11 CTS
12 DTR
13 RI
14 RTS
15 RXD
