2 - 36 MC9190-G Integrator Guide
Figure 2-37
Connection Settings
9. For a serial connection, select Allow connections to one of the following: check box and select the comm port
from the drop-down list.
10. For USB connection, select Allow USB connection check box.
11. Tap OK to save any changes made.
12. Connect the device to the host computer.
13. Upon connection, synchronization occurs automatically.
NOTE Every MC9190-G should have a unique device name. Never try to synchronize more than one MC9190-G to
the same name.
NOTE The cradle requires a dedicated port. It cannot share a port with an internal modem or other device. Refer to
the computer user manual supplied to locate the serial port(s).
