Chord Type Notes Added to Played Note
Octave Octave
1-3 3rd
1-5 5th
1-3-5 3rd and 5th
1-4-5 4th and 5th
1-3-5-7 3rd, 5th, and 7th
1-4-7 4th and 7th
Scales and Chords: Visual Feedback on the Pads
When scales and/or chords are enabled, the LEDs of the pads keep you informed at any time
on the current scale and chord configuration. The default lighting behavior of your pads is
modified by the Scale and Chord engine as follows:
When Chord Mode is set to Off or Harmonizer, pads of root notes are fully lit:
Type of Pad (for Selected Scale)
LED in Default
State
LED when Pad Triggered
Root notes Fully lit Flash
Other pads Dimly lit Flash
Note that if Chord Mode is set to Harmonizer, pads triggered as part of the chord will also
flash.
When Chord Mode is set to Chord Set, pad 1 is fully lit:
Type of Pad LED in Default
State
LED when Pad Triggered
Pad 1 Fully lit Flash
Pads 2–12 Dimly lit Flash
Pads 13–16 Off (pad inactive)
Playing on Your Controller
Performance Features
MASCHINE STUDIO - Manual - 273
