NEC Electra Elite IPK II System - Page 1142

Document Revision 4C Electra Elite IPK II
2 - 1118 Wireless - DECT
This limits the combinations to those shown in the table below:
 Wireless – DECT is not supported with ACD.
 Off-Hook signaling is not supported for Wireless – DECT telephones.
Default Setting
None
System Availability
Terminals
Wireless – DECT Telephones
Required Component(s)
 BSU(4M)-U20 ETU (Master)
 BSU(2S)-U20 ETU (Slave)
 BSU(6S)-U20 ETU (Slave)
 Base Station (BS)
 Tool for Wireless Line ETU (Windows Application) included with the BSU(4M)-U20 ETU.
No. Slot N-2 Slot N-1 Slot N
No. of Base
Stations
Note
1 None None BSU(4M) ETU 4
2 None BSU(2S) ETU BSU(4M) ETU 6
3 None BSU(6S) ETU BSU(4M) ETU 10
4 BSU(2S) ETU BSU(2S) ETU BSU(4M) ETU 8
5 BSU(6S) ETU BSU(2S) ETU BSU(4M) ETU 12
6 BSU(2S) ETU BSU(6S) ETU BSU(4M) ETU 12
7 BSU(6S) ETU BSU(6S) ETU BSU(4M) ETU 16
