NEC Electra Elite IPK II System User Manual

Electra Elite IPK II Document Revision 4C
Call Appearance (CAP) Keys 2 - 107
Off-Hook Signaling
Programmable Function Keys
Secondary Incoming Extension
User Programming Ability
Virtual Extensions
Programming
 14-05-01 Trunk Group – Trunk Group Number
Assign trunks to trunk groups (1~100).
 15-07-01 Programmable Function Keys
Assign a key as a CAP key (code
8) plus a CAP orbit number (01~64).
 20-06-01 Class of Service for Extensions
Assign a Class of Service (1~15) to extensions.
 20-11-19 Class of Service Options (Hold/Transfer Service) – Hold/Extended Park
Determine whether an extension Class of Service should allow normal (0) for PRG 24-01-06, or
extended Park (1) for PRG 24-01-07).
 24-01-02 System Options for Hold – Hold Recall Callback Time
A call parked longer than the programmed time recalls the extension where it was initially
parked.
 24-01-06 System Options for Hold – Park Hold Time - Normal
Set the Park Hold Time (0~64800 seconds). A call parked longer than the programmed time
recalls the extension where it was initially parked.
Refer to Flexible System Numbering on page 2-447 for setting Flexible Timeouts for Class of
Service.
 24-01-07 System Options for Hold – Park Hold Time - Extended (Recall)
Set the Extended Park Hold Time (0~64800 seconds). A call parked longer than the
programmed time recalls the extension where it was initially parked.
