NEC Electra Elite IPK II System User Manual

Document Revision 4C Electra Elite IPK II
2 - 796 PC Programming
If using WebPro, a user can connect only via IP. To connect, launch a web browser (i.e., IE or Mozilla)
and enter the IP address of the switch (refer to Figure 2-22 WebPro Login Screen.)
Conditions
 The hardware/software requirements for the host PC running the PCPro application are:
Figure 2-22 WebPro Login Screen
Item Requirement
CPU
Pentium III 598MHz (minimum)
Pentium 4 2.5GHz (recommended)
Memory 128 MB of RAM, 256 MB (recommended)
Disk Space 25MB (minimum)
Operating System (OS)
MS Windows 2000 or higher
Windows XP (recommended)
Browser MS Internet Explorer 6.0
Network
IP and/or RS232 connection to the KTS
IP Address of the KTS (PRG
10-12-01 on the KTS)
User Name/Password is taken
from PRG 90-02 on the KTS
