SECTION 3
TOOLBOX SERVICE FEATURES
41
Printer Control Configuration Screen:
Allows technician to make fine adjustments as to how a job is fed into and through the Printer and how it
will print.
You can also return the Printer to the default settings by pressing the “Reset to Factory Settings” button.
NOTE: After changing the settings on this page and pressing Submit, you must properly power-down the
Print Engine, before they will be saved. If you skip this step the printer will revert to the previous settings,
after a power loss or improper power off (turning off Main Power Switch without powering down the Print
Engine).
CAUTION!
With exception to the features outlined below in red; please don’t make changes from default unless
instructed by a Tier 2 Support Agent or following a written procedure from this manual.
If you aren’t sure if the settings are correct or not, press the “Reset to Factory Settings” button. Then
properly power the Print Engine off/on, to save these changes into non-volatile memory.
Notes about “jobmid_cutsheet”:
It is normal for the “jobmid_cutsheet” value to change automatically with the “Mid Job Servicing” level set
in the User Interface screen (values shown below). If you type in a “custom” value, it will be reset to the
value set by the “Mid Job Servicing” level in the User Interface screen.
Mid Job Servicing setting = jobmid_cutsheet value
Off = 32,000 meters
Level 1 = 500 meters
Level 2 = 375 meters
Level 3 = 250 meters
Level 4 = 100 meters
Default = 14,000 millimeters (14 meters)
