SECTION 6
MAINTENANCE
164
Replacing the Sheet Separators
The Sheet Separators insure separation of the pieces as they are being fed. If you experience double sheet
feeding and cannot adjust the Separators to prevent it, they should be replaced. Replacement of the Sheet
Separators is not difficult.
1. Turn off the Printer and unplug it from the power source.
2. Release the Separator-by loosening the
Locking Knob and moving the Paper Side
Guides to their maximum open position.
3. Lower the Separators so that they touch the
Feed Roller.
4. Remove the screw [A] and the Separator
Cover [B]. Then remove the Separator [C] by
prying it out of the holder.
5. Install a new Separator in place and replace
the Separator Support and screw.
To Next Page
