SECTION 5

DISASSEMBLY AND ASSEMBLY

Right-hand (Non-Operator) Side Cover

1. Remove the (2) screws at

the top of the Cover. Then

remove the (3) screws from

the bottom of the Cover.

Major Components under Right-Hand (Non-Operator) Side Cover

1. Interface PC Board

2. Main Power Plug,

Switch, Fuse

3. USB Connector

4. Network Connector

5. Feed Clutch and Feed

Roller Assembly

6. Encoder

7. Encoder Sensor

8. Drive Belt

9. Drive Motor & Roller

Drive Pulley
