Like the main AutoTest screen, Wired Profile
tests are summarized on cards. Tap a card to
view individual test screens.
Each test icon (except the switch) displays
green, yellow, or red to indicate the status of the
completed test step: Success/Warning/Fail. The
Switch Test card shows the name and port of
the nearest switch, but does not turn green to
indicate success.
When Wired Profiles Run Automatically
The last enabled Wired Profile in the currently
active Profile Group runs automatically when a
copper cable is connected or energy is detected
to the top RJ-45 port, unless the AutoTest app is
open in the foreground and there is more than
one enabled Wired Profile. A Wired Profile does
not start automatically if Periodic AutoTest is
running.
After a Wired Profile runs, a wired network link is
maintained for further testing. Wired Test Port
linkage is indicated in the top Status Bar with
this notification icon: .
AutoTest App and Profiles
217
