netAlly ETHERSCOPE nXG User Manual

Tapping the blue linked switch name opens a
Discovery Details screen for the switch, where
the user can investigate the cause of the
Warning.
Layer 2 Devices
Layer 2 devices can be switches or APs.
Layer 2 Switches
The image below displays an example of a Path
Analysis to a device on the local broadcast
domain with two switches in the Layer 2 portion
of the path.
Path Analysis App
635
