BSSID RF and Traffic Statistics
Tap the RF and Traffic Statistics card to open
the RF and Traffic Statistics screen. This screen
displays the BSSID and channel number at the
top of the screen as well as informational
graphs.
To pan and zoom on the graphs, you can swipe,
double tap, and move the slider under each
graph. Tap the Restore icon to return to the
full graph. (See the Trending Graphs topic for an
overview of the graph controls.)
See RF and Traffic Statistics Overview in the Wi-
Fi Details Screens topic for an explanation of the
common elements of this screen.
The Signal graph shows the signal in light blue,
noise in dark blue, and a calculated SNR.
The Channel Utilization graph uses light blue to
show 802.11 channel utilization and dark blue to
show non-802.11 utilization:
Wi-Fi Analysis App
600
