or 10G.
l
To pan and zoom on the graphs, you can
swipe, double tap, and move the slider.
See the Trending Graphs topic for an
overview of the graph controls.
5. Let the test run to completion. The Status
shows the test result (Success or Failure)
and may display additional information,
such as not connecting at the fastest
advertised speed.
About LANBERTResults
l
The color of the LANBERTicon indicates
success or failure (green for success, red for
failure).
l
The first line below the icon displays
information about the connection including:
l
Connector type
l
Speed (in bold). Other speeds shown as
grayed out values are the ones that were
advertised by the link partner but not
selected. See the Wired Link Test Results
LANBERT™ Test App
765
