netAlly ETHERSCOPE nXG User Manual

NOTE: If both the top fiber and copper ports
are connected to an active network, the
Product uses the fiber link as the Wired Test
Port connection.
Product runs Wired and Wi-Fi AutoTests,
Captures, Discovery, and other comprehensive
network analysis apps over the test ports. The
Wi-Fi test radio is primarily controlled by the
settings in applications, especially AutoTest.
You must also run an AutoTest Wired or Wi-Fi
Profile to establish a link on the Wired or Wi-Fi
test ports. If the AutoTest app is not currently
open, the last Wired Profile in the profile list
runs automatically when you power on the unit
or Product detects a new copper link in the top
Wired Test Port. Wired fiber connections and Wi-
Fi Profiles must be started manually in the
AutoTest app.
Note that the General Settings affect how you
can use the test port. (The General Settings are
accessible from the left-side navigation drawer
from most NetAlly testing apps.)
General Settings and Tools
83

netAlly ETHERSCOPE nXG Specifications

General

Wi-Fi	802.11 a/b/g/n/ac
Ethernet	10/100/1000 Mbps
Display	7-inch touchscreen
Connectivity	Wi-Fi, USB, Ethernet
Protocols Supported	TCP, UDP, IPv4, IPv6
Protocols	Ethernet, Wi-Fi, DHCP, DNS, HTTP
Measurement Capabilities	Throughput, packet loss, latency, jitter
Cable Test	Wiremap, length
Discovery	Network devices, VLANs
Network Performance Tests	Throughput, packet loss, latency, jitter
Power	AC adapter or battery
Management	Web interface
Power over Ethernet (PoE)	IEEE 802.3af/at
Operating Temperature	32°F to 122°F (0°C to 50°C)
Humidity	10% to 90% non-condensing
