ACCESS GATEWAY
System Administration 105
2. System administrators can set the properties for each room from the subscriber side of the
Access Gateway. The system automatically detects which port number the administrator is
using and allows them to enter the fields for the room corresponding to the port they are
using.
If required, click on the check box for
In Room Port Mapping to enable this feature.
3. If you enabled In Room Port Mapping, you must assign a Username and Password. You
will need these when you perform port mapping from the subscriber side of the Access
Gateway.
Go to “In Room Port Mapping” on page 107 to map rooms from the subscriber side of the
Access Gateway.
4. Select No Port Location Mapping if you are not using Port-based access.
5. If you are using an access concentration device that cannot handle VLAN IDs, select one
of the available Access Concentrator Query options:
Tut Systems Expresso
Lucent DSL Terminator
Tut MDU Lite Systems
RFC1493 Compliant Systems
RiverDelta 1000B
Elastic Networks
For security reasons, this feature should be disabled when in room port mapping
(from the subscriber side of the Access Gateway) is completed.
The devices in the following list must be assigned an IP address on the same
subnet as the Access Gateway. You must remove “old” concentrator types before
entering new ones.
