ACCESS GATEWAY
System Administration 185
2. If you want subscribers to see the ICC (pop-up window), click on the check box for
Display ICC (Information and Control Console) to enable this feature.
3. Choose which ICC you want to be displayed (either the featured ICC or the simple Logout
Console). Enable one of the following:
 ICC (Information and Control Console)
 Nomadix Logout Console
4. If you enabled either of the ICC pop-up options, you can choose a unique name for the
console. Simply type a meaningful name in the
Title field.
5. Define the physical location where you want the Nomadix Logout Console to appear on
the subscriber’s screen.
Choose one of the following options:
 Upper Left Corner
 Upper Right Corner
 Lower Left Corner
 Lower Right Corner
6. Define how you want to display the subscriber session time:
 Elapsed Time (how much time has elapsed since the start of the session)
 Time Remaining (how much time is remaining for the session)
7. You must now decide what you want the ICC to do if the subscriber closes it.
Choose one of the following options:
 Redisplay itself
 Logout (return the subscriber to a “pending” state) – valid only with RADIUS and
Post Paid PMS.
You must now assign the buttons that you want to display to subscribers.
Assigning Buttons
When assigning the redirect buttons that will appear in the ICC, you can define one
ISP Logo
Button (large button) and up to 8 smaller buttons (Button 2 through Button 9), with the
following parameters:
