ACCESS GATEWAY
System Administration 187
Assigning Banners
1. From the Subscriber Console (Information and Control Console - ICC) Setup screen, click
on the
Configure Banners link. The Subscriber Console (Information and Control
Console - ICC) Banners Setup screen appears:
You can display up to 5 banners, but they must be defined here. Banners require all
the same parameters that “buttons” use (see “Assigning Buttons” on page 185), with
the addition of 3 (three) more. These are:
Duration – Defines how long the banner is displayed in the ICC.
Start Time – This is an optional parameter that you set if you want to assign a “start”
time (for when the banner is displayed).
Stop Time – This is an optional parameter that you set if you want to assign a “stop”
time (for when the displayed banner closes).
When assigning images and times for banners, refer to: “Pixel Sizes” on page 188 and
“Time Formats” on page 189.
