Diagnostic information 2-21

846.06

Front calibration strip has excessive

dark area

Front excessive variability for Mono, Red,

Green, or Blue. Go to “CCD service

check” on page 2-65

846.07

Front magnification exceeds limits Rear excessive variability for Mono, Red,

Green, or Blue. Go to “CCD service

check” on page 2-65

847

Modem Failure The Configuration ID bit that describes the

device’s modem doesn’t match the actual

modem installed in the device.

847.01

Fax Storage The amount of flash storage available on

the device is too small. Note: The NAND

Flash partition can shrink as bit failures

cause blocks to be invalidated. Go to

“Format Fax Storage” on page 3-34. If

the issue is not fixed, replace the controller

board. Go to “Controller board removal”

on page 4-18.

847.02

Fax Storage The devices’ flash partition is invalid or

unavailable. Go to “Format Fax Storage”

on page 3-34. If the issue is not fixed,

replace the controller board. Go to

“Controller board removal” on

page 4-18.

848

Modem/Config ID Mismatch A device doesn’t have a modem installed,

even though its Configuration ID indicates

that a modem should be present.

848.01

Modem/Config ID Mismatch A device has a modem installed, but its

Configuration ID indicates that a modem

shouldn’t be present.

849

HD/Config ID Mismatch A device doesn’t have a hard drive

installed, even though its Configuration ID

indicates that a hard drive should be

present.

849.01

HD/Config ID Mismatch A device has a hard drive installed, but its

Configuration ID indicates that a hard drive

shouldn’t be present.

9xx service errors

900.xx Service

RIP Software

Unrecoverable RIP software error/

illegal trap.

Go to “90x.xx error” on page 2-31.

902.xx Service

Engine Software
