Chapter 10
10-6
Appendices
■ Object Details
10-2-4 Assembly Objects: Class 04 Hex
Assembly objects are objects related to remote I/O operations. Remote I/O operations are configured
with these objects for communications.
■ Support Service Code
Instance Attribute Name Content Setting range Default Read Write Size
00 01 Object Software
Revision
Indicates class 03 soft-
ware revisions. The revi-
sion value is advanced
whenever there is a
change.
--- 0001 Yes No Word
01 01 MAC ID Switch setting: 00 to 63
The communications node
address is specified by the
switches and cannot be
overwritten.
--- 00 Yes No Byte
Switch setting: 64 to 99
The communications node
address is specified by the
software settings. The
default setting is 00.
00 to 63 00 Yes Yes Byte
02 Baud Rate Indicates the baud rate.
00: 125 Kbps
01: 250 Kbps
02: 500 Kbps
--- 00 Yes No Byte
03 BOI --- --- 0000 Yes No Word
04 Bus-off Counter --- --- 0000 Yes No Word
05 Allocation Infor-
mation
Indicates DeviceNet com-
munications connection
information.
Note: Cannot be written
for explicit mes-
sages. (Error is
returned.)
--- 00 00 Yes Yes Byte ×
2
Service code number (hex) Service
0E Get attribute single
10 Set attribute single
