Omron fh-1 series User Manual

4 Setting the Controller
4 - 18
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
OK:Supported processing item, RST: Processing item with restricted support, ---:Unsupported processing item
Processing item
Sup-
port
Processing item
Sup-
port
Processing item
Sup-
port
Camera Image Input OK Back Ground Suppression OK Transfer Position Data OK
Camera Image Input FH OK Brightness Correct Filter OK Calc Axis Move OK
Camera Image Input FHV
OK
Color Gray Filter
OK
Calc Axis Move by Multi-
point
OK
Camera Image Input HDR --- Extract Color Filter OK Detection Point OK
Camera Image Input HDR
Lite
---
Anti-Color Shading
OK
Camera Calibration
OK
Camera Switching OK Stripes Removal Filter II OK Data Save OK
Measurement Image
Switching
OK
Polar Transformation
OK
Conditional Branch
OK
Search OK Trapezoidal Correction OK End OK
Flexible Search OK Machine Simulator OK DI Branch OK
Sensitive Search OK Image Subtraction
RST
(*1)
*1. The [Subtract only] measurement mode is not supported.
Control Flow Normal ---
ECM Search OK Advanced Filter OK Control Flow PLC Link ---
EC Circle Search OK Panorama OK Control Flow Parallel ---
Ec Corner OK Calculation OK Control Flow Fieldbus ---
Ec Cross OK Line Regression OK Selective Branch OK
Shape Search II OK Circle Regression OK Data Output OK
Classification OK Precise Calibration OK Parallel Data Output OK
Edge Position OK User Data OK Parallel Judgement Output OK
Edge Pitch OK Set Unit Data OK Fieldbus Data Output OK
Scan Edge Position OK Get Unit Data OK Result Display OK
Scan Edge Width OK Set Unit Figure OK Display Image File OK
Circular Scan Edge Posi-
tion
OK
Get Unit Figure
OK
Display Last NG Image
---
Circular Scan Edge Width OK Trend Monitor --- OCR OK
Color Data OK Image Logging
RST
(*2)
*2. Images from odd numbered measurements and from even numbered measurements are logged in separate folders.
OCR User Dictionary OK
Gravity and Area OK Image Conversion Logging
RST
(*2)
Conveyor Calibration ---
Labeling
OK
Data Logging
OK
Conveyor Panorama Dis-
play
---
Label Data
OK
Elapsed Time
OK
Photometric Stereo Image
Input
OK
Defect OK Wait OK Display image hold ---
Precise Defect OK Focus OK Conditional execution (If) OK
Fine Matching
OK
Iris
OK
Conditional execution
(Else)
OK
Character Inspection OK Unit Macro OK loop OK
Date Verification OK Unit Calculation Macro OK Loop suspension OK
Model Dictionary OK Parallelize OK scene OK
2D Codes OK Parallelize Task OK Select execution (Select) OK
Circle Angle OK Statistics --- Select execution (Case) OK
Shape Search III
OK
Calibration Data Refer-
ence
OK
System information
OK
Intersection OK Position Data Calculation OK Manual Position Setting ---
Barcode OK Stage Data OK 2DCode II OK
Glue Bead Inspection OK Robot Data OK Result output (I / O) OK
Position Compensation OK Vision Master Calibration --- Result output (Message) OK
Filtering OK PLC Master Calibration ---
