10 Advanced Usage
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
10-2 Multi-trigger Imaging Processing with
Any Timing [Multi-trigger Imaging]
10
10-2-4 About Multi-input Function (Multi-trigger Imaging)
The Multi-input function allows sequential high-speed image input. Next STEP signal can be received
when the Input image is completed.
Multi-input function can be used with Multi-trigger Imaging processing. Refer to the following application
examples of Multi-trigger Imaging.
• Multi-trigger Imaging Flow Example
10-2-4 About Multi-input Function (Multi-trigger Imaging)
STEP1
STEP2
