9 Saving/Loading Data
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
9-1 Saving Data to the FH
series/FZ5 series
9
9-1-1 About Saving Areas
9-1 Saving Data to the FH series/FZ5
series
This section describes how to save and load setting data and logged image data.
The following saving areas can be used with the Sensor Controller.
9-1-1 About Saving Areas
Saving area Description Save operation
Controller Flash memory in
the Controller
The settings data (system data, scene data, and scene
group data) is saved to this area when you click the [Data
save] button. Data is held even after the power supply is
turned OFF. When you restart the Controller, the Controller
loads and enables the settings data in the flash memory.
[Function] −
[Data save] or
the [Data save]
button
Controller mem-
ory (RAM)
This is the area where images are temporarily stored when
logging images using the logging function. This memory is a
ring memory. Images will be overwritten starting with the old-
est image if the maximum number of save images is
exceeded.
[Function] −
[Save to file] or
[Function] −
[Screen capture]
RAM disk in the
Controller
• You can use this memory as a temporary file save destina-
tion.
• The data is cleared when you turn OFF the power supply
to the Controller. As this is memory inside the Controller,
files can be saved and read faster than when using exter-
nal storage.
• The RAMDisk memory is as follows.
• FH series/FZ5-800/1100/1200 series: 256 MB
• FZ5-L series/FZ5-600 series: 40 MB
• The RAMDisk data can be sent to or received from exter-
nal devices using FTP.
External
storage
USB memory This memory is used to back up setting data as a precau-
tion, to copy setting data to another Controller, and to load
data to a computer.
SD memory card
(FH series only)
microSD card
(FHV series only)
Shared folder on
a computer con-
nected to the net-
work
