8 - 3
8 Setting Windows
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
8-1 Windows
8
8-1-1 Types of Windows
8-1 Windows
There are 9 windows (with layout numbers 0 to 8) that you can use to set and operate an FH/FHV/FZ5.
Additional Information
If necessary, you can change layout 0 and layout 1 from the default adjustment window and run
window and use them for other purposes.
Important
If the operation mode is set to Multi-line Random-trigger Mode, you must create a layout for
each line. Refer to
Multi-line Random-trigger Mode on page 4-19.
8-1-1 Types of Windows
Layout Application
Layout 0 Layout 0 is the adjustment window by default.
Refer to 8-2-1 Main Window (Layout 0): Adjustment Window (Default) on page 8-11.
Layout 1 Layout 1 is a run window by default.
Refer to 8-2-2 Main Window (Layout 1): Run Window (Default) on page 8-12.
Layout 2 to layout 8 Layouts 2 to 8 are for user-defined purposes and are created as they are needed.
Refer to 8-3 Arranging Windows [Layout Functions] on page 8-14.
For example, if more than one line is being controlled, you can set and use a separate
window for each line.
Refer to Multi-line Random-trigger Mode on page 4-19.
