9 Saving/Loading Data
9 - 52
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
6 Click [OK].
The data will be saved to the save destination.
The character code of the downloaded CSV file is Unicode (UTF-8).
You can open this file with the Notepad in Windows. When using another editor to open the file, set the
character code to Unicode (UTF-8).
The CSV file format is as follows:
Double-byte characters are enclosed in the double quotation marks (").
Refer to the individual processing items and the external reference tables in the Vision System FH/
FHV/FZ5 Series Processing Item Function Reference Manual (Cat. No. Z341) for the parameters for all
data. Only data with "Set/Get" attribute can be downloaded.
Output Example of CSV File:
9-10-2 About Downloaded CSV Files
SceneTitle,Scene title name,Author,Note
#Processing item number in the flow,Processing item identifier,Processing unit title identifier,data title,data
SceneTitle Scene 0
#0 Camera image Camera Image Input
#1 Search Search
outputCoordinate Output coordinates 0
calibration Calibration 0
overallJudge Reflect to overall judgement 0
searchMode Search mode 0
rotation With/without rotation 0
endAngle Upper limit of the rotation angle 180
startAngle Lower limit of the rotation angle −180
angleSkip Skipping angle 5
smartMode Smart mode 1
stability Stab.(CR) 12
accuracy Prec. 2
searchSpeed Stab.(PT) 3
referencePosX Reference X 0
referencePosY Reference Y 0
detectionPosX Detection point X 0
detectionPosY Detection point Y 0
subPixel Sub-pixel 0
candidateLevel Candidate Point Level 70
upperX Upper limit of measure X 99999.9999
lowerX Lower limit of measure X −99999.9999
upperY Upper limit of measure Y 99999.9999
lowerY Lower limit of measure Y −99999.9999
upperAngle Upper limit of the angle 180
lowerAngle Lower limit of the angle −180
upperCorrelation Upper limit of corr. 100
lowerCorrelation Lower limit of corr. 60
savemdlimg Save registered model 0
thersDetail Candidate Point Level 75
sort Sort condition 1
