6 Performing Measurement and Adjustment
6 - 46
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
Delete registered images.
1 Click [Tool] -> [Registered image manager] on the Main window.
“Registered image” window is displayed.
2 Select the image to delete and clock [Delete].
“Precaution” message is displayed.
3 Click [Yes].
The selected image is deleted.
A registered image can be loaded as a measurement image.
1 Click [Tool] -> [Registered image manager] on the Main window.
“Registered image” window is displayed.
2 Select the image to load and click [Save].
The selected image is loaded into the selected folder.
6-7-4 Deleting Images
6-7-5 Loading Images
Icon/Button Function Description
Save Saves the image in the displayed registration destination folder
(sub-folder) to the specified folder. Specifying the destination folder
is done via the displayed folder selection dialog box.
