Omron fh-1 series User Manual

A - 39
Appendices
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
A-13 About Limits on the Number of Image Input Processing Items
Used
A
A-13 About Limits on the Number of Image
Input Processing Items Used
For the FZ5-L/FZ5-600 series, The number of image input processing items that can be used within
one scene is limited by the combinations of the camera. (Units that are not used in conditional branch-
ing, etc. are also targeted.)
If the limit is exceeded, a measurement NG (image mismatch) occurs due to a memory shortage during
measurement.
Please use within this processing items limitation.
 Image input related processing items
Target processing items are as follows.
Important
• If there is one or more "Sensitive Search" in the flow, the number of image input items that
can be used is only reduced by one.
• In the case of the FH series / FZ5-800/1100/1200 series, the number of processing items is
not limited and can be registered as long as there is sufficient free memory. Note, however,
that a warning message is displayed when the available memory drops to below 1 GB. In this
case, adjust the inspection flow to ensure at least 1 G of available memory.
Camera used Number of image input related processing item restriction
0.3 mega pixels color camera 81
0.3 mega pixels monochrome camera 245
Intelligent Compact Digital Camera (FZ-SQ) 69
2 mega pixels color camera 13
2 mega pixels monochrome camera 39
5 mega pixels color camera 6
5 mega pixels monochrome camera 19
Item Processing item Item Processing item
Loading Images Camera Image Input Performing image com-
pensation
Anti Color Shading
Camera Image Input HDR Stripes Removal Filter II
Camera Switching
Polar Transformation
*1
*1. When using a Polar Transformation, each image input related unit after Polar Transformation may consume
up to a maximum of 2 items.
Camera Image Input FH Image Subtraction
Camera Image Input HDR Lite
Advanced Filter
*2
*2. For each unit, 4 items are consumed for Advanced Filter.
Performing image
compensation
Position Compensation Machine Simulator
Filtering Panorama
Background Suppression Trapezoidal Correction
Brightness Correct Filter Inspection and mea-
surement support items
Precise Calibration
Calibration Data Reference
Color Gray Filter Display result to the
window
Display Image File
*3
*3. Image file display consumes the number of image setting value items per unit.
Extract Color Filter
Display Last NG image
*4
Conveyor Panorama Display
*4. Display Last NG Image consumes the number of save setting value items per unit.
