9 - 5
9 Saving/Loading Data
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
9-1 Saving Data to the FH
series/FZ5 series
9
9-1-2 External Drive Names
Drive Names for USB Devices
Sensor Controller has two or four USB connectors. If more than one USB memory device is
inserted, specify the USB memory drive that is to be the destination.
• FZ5-L series/FZ5-600 series
The drive names of USB memory devices are USBDisk, USBDisk2, USBDisk3 and USBDisk4
according to the sequence in which devices are inserted into the Controller.
If the Controller, however, is started with more than one USB memory device inserted, drive
names will be assigned based on the ports in which the USB memory devices are inserted.
Depending on the Controller type, USB memory devices are recognized and drive name are
assigned using the following sequence.
• Controller with Integrated Panel
1: Left side on the front - 2: Right side on the front - 3: Front on the side - 4: Back on the side
• Box-type Controller
1: Lower left on the front - 2: Lower right on the front - 3: Upper left on the front - 4: Upper right
on the front
• FH series/FZ5-800/1100/1200 series
USB devices are assigned as drives E:\, F:\, G:\ and H:\ in the order in which they are inserted.
Drive Name of SD Memory Card
When FH series Sensor Controller is used, "M:\" is assigned as a fixed drive.
Box-type Controllers
If USB memory devices are separately connected to adjacent USB connectors, the contact
between USB memory devices may possibly lead to failure or damage.
USB hub
When connect the USB memory using USB hub, the drive name can be differ as a previous
saved. If you want fixed name, directly connect the USB port without USB hub.
9-1-2 External Drive Names
